Zone Chart
The Zone Chart shows an XBar line (average of the subgrouped measurements) along with the first, second and third sigma zones. The chart is depicted showing the zones in green, yellow and red color so you can see where your process is running. In addition, there are appropriate statistics to go along with the chart. The points are all selectable for further drill down.
|
|
